Sähkövinssi 12V 5440 kg, vaijeri 26m/9,5mm. Varustettu rullaohjaimella ja johdollisella kauko-ohjaimella, välityssuhde 265:1, moottori 5,5HP, automaattijarrulla, vesitiivis vaihteisto. Toimitus vain matkahuollon kautta (43kg).
Detailed Product Description
Single Line Rated Pull: 12000Lb
Motor: 5.5hp / 4,0kw.
Control: Remote Switch; 12' ( 3.7m ) lead
Gear Train: 3-Stage Planetary
Gear Ratio: 265: 1
Clutch: Sliding Ring Gear
Brake: Automatic In - the - Drum
Drum Size: Diameter 2.52" ( 64 mm ) Length 8.82" ( 224 mm )
Wire Rope: 87' x 3/8" Diameter ( 26 m x 9.5 mm Diameter )
Fairlead: 4 - way Roller Fairlead
Remote Control: Included
Recommended Battery: 650 CCA minimun for winching
Battery Leads: 25 mm2 x 72' (1.83 m )
Finish: Gray
Overall Dimensions: 21.3" (L) x 6.3" (W) x 8.6" (H)
Mounting Bolt Pattern: 10.0± 0.015IN x 4.5± 0.01IN
|
